Fujifilm X-H2 + XF 16-80mm + XF70-300mm

Fujifilm X-H2

The FUJIFILM X-H2 mirrorless system camera is the new flagship model in the award-winning X series, whose APS-C cameras combine the highest image quality with a compact design. Like its recently introduced sister model, the FUJIFILM X-H2S, the X-H2 represents the state of the art in camera technology. It is exceptionally powerful and is designed in every respect to meet even the highest professional demands. While the X-H2S is characterized above all by its enormous speed, which can be seen in the lightning-fast data processing and the precise AF tracking of moving objects, the advantages of the X-H2 lie in its very high sensor resolution and outstanding detail reproduction.

At the heart of the X-H2 is the new 40.2 megapixel X-Trans CMOS 5 HR sensor *1 , which is optimally matched to the fast X-Processor 5. The camera offers the highest resolution of the X series to date, both for photos and videos. It is the world's first *2 APS-C camera that can record video in 8K/30p Apple ProRes quality *3 directly to the memory card.

The X-H2 offers many advanced features, such as ISO 125 as the lowest standard sensitivity, a fastest shutter speed of 1/180,000 sec. with electronic shutter and the "Pixel Shift MultiShot" function. It also has numerous functions and interfaces that make professional-quality photography easier than ever. These include subject recognition autofocus based on deep learning technology, which identifies and tracks various subjects (e.g. animals or vehicles), the integrated five-axis image stabilizer, which provides a shutter speed advantage of up to seven f-stops (EV) *4, an electronic viewfinder with 5.76 million pixels and 0.8x magnification, and a memory card slot for CFexpress Type B cards *5 , which allow the technological potential of the X-H2 to be exploited to the full.

High-resolution X-Trans CMOS 5 HR sensor and X-Processor 5

The 40.2 megapixel X-Trans CMOS 5 HR sensor with backside exposure has an improved image processing algorithm, which enables a very high resolution without disturbing image noise and thus an overall outstanding image quality.

A further developed pixel structure results in a greater amount of light on the sensor, so that ISO 125 is now available as the standard sensitivity and no longer needs to be selected via the extended ISO range. The new sensor can also be controlled with extreme precision, allowing ultra-short exposure times. The fastest shutter speed of the electronic shutter has been increased by 2.5 EV steps from 1/32,000 sec. to 1/180,000 sec.

The new sensor opens up new creative possibilities, especially when shooting in bright surroundings. You can now achieve the attractive bokeh effect with the aperture open on sunny summer days or on the ski slopes and freeze fast movements with ultra-fast shutter speeds for maximum sharpness.

Ultra-high-resolution photos and HEIF image format

With the "Pixel Shift Multi-Shot" function, the camera takes 20 high-resolution RGB images one after the other in raw data format, whereby the image sensor is minimally shifted after each exposure. The resulting individual photos can be combined into a single image file with a resolution of 160 megapixels using the free "Pixel Shift Combiner" software. This function is particularly interesting for photographic documentation and digitization in the fields of art and culture as well as for high-quality still life and product photography.

The X-H2 supports the HEIF image format, which delivers 10-bit image files that are up to 30 percent smaller than standard JPEG files. The integration of these two features underlines FUJIFILM's reputation for delivering the highest quality images straight from the camera.

Professional videos in 8K quality

With the X-H2, ultra-high-resolution moving image recording becomes the professional standard: the new sensor allows video to be recorded in the future-oriented 8K/30p 4:2:2 10-bit format. The camera body of the X-H2 has been designed to quickly dissipate the heat generated by the sensor and processor. As a result, up to 160 minutes *6 can be recorded in 8K quality without interruption.

The 8K sensor also offers many advantages in 4K workflows. For example, the camera uses the depth of detail of the 8K data for internal oversampling to generate a 4K image of outstanding quality.

The digital zoom function *7 of the X-H2 also makes use of the high resolution of the 40.2 megapixel sensor. This makes it possible to zoom into the image with up to 2x magnification for 4K recordings. In conjunction with the XF18-120mmF4 LM PZ WR, the camera seamlessly switches to digital zoom once the maximum optical focal length has been reached, effectively doubling the focal length.

Efficient post-production

The X-H2 supports three Apple ProRes codecs: ProRes 422 HQ, ProRes 422 and ProRes 422 LT. When recording videos up to 4K resolution, proxy movies *8 (ProRes 422 Proxy) with a low bit rate can also be recorded in parallel. As these have a smaller file size, they are suitable for efficient workflows with reduced workload in post-production.

In combination with a compatible external HDMI recorder from Atomos or Blackmagic Design, 12-bit RAW video files can also be recorded. These can be saved as Apple ProRes RAW or Blackmagic RAW in up to 8K resolution with frame rates of up to 29.97 frames per second.

In addition to the familiar F-Log, the X-H2 also supports F-Log2, which offers an extended dynamic range of more than 13 f-stops and therefore more creative freedom in video editing.

Intelligent autofocus for maximum sharpness of detail

The X-H2 is equipped with an innovative autofocus system that allows the photographer to concentrate fully on the subject and image composition. They can rely on the camera to focus reliably and precisely on the subject.

The powerful X-Processor 5 of the X-H2 offers an object-oriented autofocus function with subject recognition based on artificial intelligence. The algorithm developed using deep learning technology not only recognizes and tracks people's faces and eyes, but also animals, birds, cars,
motorcycles, bicycles, airplanes and trains reliably in focus.

The 40.2 megapixel sensor has more phase detection pixels than previous models in the X series, resulting in even more precise focusing in AF-S mode, for example in landscape or portrait shots. In addition, the X-H2 (like the X-H2S) has a new AF algorithm for predicting object movement, which enables even more reliable focus tracking in continuous focus (AF-C).

As 8K videos require particularly precise focusing, the VideoAF algorithm has also been optimized. There is also a new focus indicator, which makes manual focusing easier when filming and can be used in combination with the focus peaking function.

Top features and ease of use

The FUJIFILM X-H2 is equipped with integrated five-axis image stabilization (IBIS). This enables sharp shots at shutter speeds up to seven EV steps slower and thus offers a decisive advantage in many situations, e.g. in low light.

The electronic viewfinder of the X-H2 offers a high-resolution viewfinder image with 5.76 million pixels and 0.8x magnification. The high refresh rate of approx. 120 frames per second ensures a natural representation of even very fast movements. The viewfinder image is also optimally corrected and free of parallax errors and distortion that typically occur when the eye position changes.

The X-H2 is built to withstand the rigors of everyday professional use. Like the X-H2S, it has a weatherproof housing that is sealed against the ingress of moisture and dust at 79 points and is fully operational even at temperatures as low as minus 10 degrees Celsius.

The sub-display on the top of the camera, the rear LCD monitor with 1.62 million pixels, the individually configurable AF ON button and the separate video recording button provide additional ease of use. The X-H2's dual memory card slot supports both conventional SD cards and CFexpress Type B cards, allowing the full potential of the camera to be exploited for continuous shooting and video recording. *9

In addition, the X-H2 (like the X-H2S*10) is compatible with the FT-XH file transmitter, which allows wired LAN and wireless WLAN tethered video recording. Up to four X-H2 and X-H2S can be controlled via a browser application. For example, the recording parameters for each camera can be checked and adjusted and video recording can be started and stopped synchronously for all cameras. It is also possible to save, copy and load camera settings. *11

*1 X-Trans is a trademark or registered trademark of FUJIFILM Corporation.
*2 As of September 8, 2022, according to FUJIFILM.
*3 Apple ProRes is a trademark of Apple Inc. and is registered in the U.S. and other countries and regions.
*4 In combination with the FUJINON XF35mmF1.4 R.
*5 CFexpress™ is a trademark or registered trademark of the CompactFlash Association.
*6 Maximum recording time at an ambient temperature of 25 degrees Celsius and the camera settings: auto power-off temperature "High", H.265 4:2:0, 200Mbps bit rate and the vertical battery grip VG-XH with a total of three batteries inserted. The recording time depends on the remaining battery charge and the type and capacity of the memory card used. If the device heats up, recording may stop automatically.
*7 Digital zoom is available in three video modes: 4K HQ, 4K DCI HQ and Full HD.
*8 The proxy function is not available for 8K/30P and 8K/25P recordings.
*9 A list of compatible memory cards can be found on the FUJIFILM website.
*10 An update to the latest firmware is required for the X-H2S to use this function.
*11 The camera settings can be saved to and loaded from a computer or tablet.

Fujifilm XF 16-80mm F4 R OIS WR

The "FUJINON XF16-80mmF4 R OIS WR" is a compact and weather-sealed Zoom lens for the FUJIFILM X series mirrorless system cameras. It has a continuous aperture of F4 and covers a focal length range of 16-80 mm (equivalent to 24-122 mm KB). In addition, it offers a minimum shooting distance of 35 cm over the entire Zoom range. The maximum magnification is 0.25x.

The Zoom lens has an optical image stabilization system that allows up to 6 EV steps slower shutter speeds. This means that the lens can be used in a variety of situations, e.g. even in difficult lighting conditions.

In addition, the XF16-80mm offers particularly fast, precise and quiet internal focusing, which is controlled by a powerful stepper motor.

It weighs only 440 grams and is therefore around 40 percent lighter than a comparable lens for a 35 mm system. With a length of 88.9 mm and a diameter of 78.3 mm, it is very compact.

Fujifilm XF70-300mm f4-5.6 R LM OIS WR

The Fujinon XF70-300mm F4-5.6 R LM OIS WR offers a focal length range of 70 to 300 mm (equivalent to 107 to 457 mm KB) to capture distant or small objects full frame. A fast autofocus motor, a 5.5-stop optical image stabilizer and a weather-sealed body ensure perfect shots in a variety of photographic situations.

With the Fujinon XF1.4X TC WR and Fujinon XF2X TC WR teleconverters, the range of the new telephoto Zoom lens can be extended up to 600 mm (equivalent to 914 mm KB). Even distant subjects appear very close and can be photographed in close-up.

Large Zoom range in a handy housing

The XF70-300mm F4-5.6 is the ideal choice for photographing subjects from a great distance. People or animals can be brought into the picture from a great distance. This enables brilliant images to be taken in many everyday and memorable moments. The optical design comprises 17 elements in 12 groups, including an aspherical lens and two ED elements to minimize optical aberrations.

Despite the large focal length range and high image quality, the Tele-Zoom lens is surprisingly compact and lightweight with a length of 132.5 mm, a diameter of 75 mm and a weight of just 580 grams. The Tele-Zoom XF70-300mm F4-5.6 is therefore the ideal complement to the standard Zoom XF16-80mm F4 R OIS WR. Together, the two handy lenses offer a comprehensive Zoom range from 24 mm to 457 mm (equivalent to KB), but are considerably lighter and more compact than corresponding 35 mm lenses.

Compatible with 1.4x and 2.0x teleconverters

The Zoom range of the XF70-300mm F4-5.6 can be extended by a factor of 1.4 or 2.0 with the Fujinon XF1.4X TC WR and Fujinon XF2X TC WR teleconverters without reducing the performance of the phase AF. The longest possible focal length is therefore 630 mm or 914 mm (equivalent to KB). The speed is reduced accordingly by 1.4 or 2.0 f-stops.

Image stabilization over 5.5 EV steps

The optical image stabilizer (OIS) of the XF70-300mm F4-5.6 enables sharp hand-held shots even at long focal lengths and in low light. This effectively compensates for camera shake caused by slower shutter speeds over 5.5 EV steps.

If the lens is used on cameras with integrated five-axis image stabilization (IBIS), such as the Fujifilm X-T4 or Fujifilm X-S10, even greater stabilization is achieved. The combination of both systems not only compensates for typical camera shake that occurs during photography, but also for linear shifts that occur when the camera is pulled along or panned.

Fast and quiet autofocus

The autofocus of the XF70-300mm F4-5.6 is based on a fast and quiet linear motor, which harmonizes perfectly with the advanced AF system of the X series cameras.

Impressive close-ups

With a close-up distance of just 83 cm, the XF70-300mm F4-5.6 produces impressive close-ups with a reproduction scale of 1:2 (equivalent to KB). In relation to the APS-C format, a magnification of 0.33x is achieved. The Zoom lens is therefore ideal for taking full-frame pictures of smaller objects such as flower blossoms. In conjunction with the XF2X TC WR teleconverter, the magnification is doubled to 0.66x, enabling macro shots with a reproduction scale of 1:1 (equivalent to KB).

Weatherproof design

Ten seals protect the interior from moisture and dust and ensure that the lens can also be used in icy temperatures down to minus 10 degrees Celsius.
